X axis 460 mm Y axis 320 mm Z axis 660 mm Max. grinding wheel diameter 200 mm Grinding spindle speed 0 – 10,500 rpm Spindle ends 2 Tool holder NCT Peak power 11.5 kW Spindle Diameter 80 mm Machine weight approx. 4,200 kg Power consumption at 400 V/50 Hz approx. 25 kVA Coolant system Tank capacity approx. 480 l Pump 120 l/min at 6 bar Min. tool diameter 3 mm Max. tool diameter 320 mm Max. tool diameter with automated work table 290 mm Max. workpiece length, peripheral grinding2) 350 mm Max. workpiece length, end face grinding2) 280 mm Max. workpiece weight 50 kg
